Panther Model 40 Motor Trim & Tilt Bracket

Panther
Product ID:
44759
Availability:
Usually dispatches in 2-5 days
$2,149.95
(No reviews yet)
Condition:
New
Current Stock:
Adding to cart… The item has been added

The Panther Model 40 Motor Trim & Tilt Bracket is a Panther marine product for the application or purpose described below.

Product information

  • Panther Model 40 Motor Trim & Tilt - Designed for clamp-on motors up to 35hp or 150lbs
  • Part#: MT-55-0040
  • This economical trim and tilt bracket is designed specifically for the casual or weekend fisherman. The Model 40 is made from 1/4" heavy duty fabricated aluminium, finished with a durable black powder coat.
  • This bracket will accommodate 2 and 4 stroke clamp-on outboards up to 150 pounds or 35hp. The powerful electro-mechanical actuator provides automatic trim and tilt, controlled by a water resistant push-button up/down electric control on a 12 foot cable.
  • Motor Plate Dimensions
  • Outboard height increase: 14.0cm
  • Top holes from top of transom plate - 2.5" to center (6.35cm)
  • Across top holes center to center - 7.5" (19.05cm)
  • Down side holes center to center - 4.5" (11.43cm)
  • Installation Manual for Model 40

Before ordering

Please compare the listed specifications and part number with your existing component. If you need help confirming compatibility, contact Jet Ski Parts Warehouse with your make, model, year and engine details.

12 months; covered by manufacturer against defects only
