Lenco Auto Glide Automatic Boat Levelling Kit - Single-Actuator System

The Auto Glide uses engine data and GPS data (depending on your installation method) to drive your boat to the most efficient running angle by adjusting your Lenco trim tabs as needed. This optimum running angle is determined during the set-up process after the installation of your Auto Glide system. Imagine that your boat's running angle is measured 25 times per second and this data is used by the new Auto Glide control box to; Automatically put your boat in the most efficient running angle, reduce the amount of bow rise of your boat during hole shot mode, eliminate bow porpoising (bow bounce), keep your boat level at all times.

Note The Auto Glide does not control the "trim" function of your engine(s) / motor(s). Please

remember to use the trim feature exactly as you would in the normal operation of your boat.

Features •  Automatic pitch and roll corrections

  Automatically trims boat to the most fuel efficient position

  Takes the trim tab operation out of the hands of the operator while allowing for manual override at the touch of a button

  Reduces time to plane

  Does not adjust during turns, allowing boat to roll naturally

  Safety - minimises bow rise and improves boat's hole shot performance

  Built-in automatic trim tab retraction

  Waterproof key pad and control box

  Three custom settings "Hold" mode and (2) "Favourite" modes

  Increase in fuel savings

  Can be installed on any boat with Lenco electric actuators

  Fast and easy installation

  2 Year warranty

(Does not Include GPS Antenna & NMEA 2000 Network)

Accessories 312860 Autoglide Adaptor Cable Smartcraft

312862 Autoglide Adaptor J1939

312864 Autoglide Adaptor Cable Yamaha

312866 Autoglide Adaptor Nmea2000

312850 Autoglide GPS Ext Kit 4.5m

Important: Specifications vary by product code. Confirm the required size or configuration before ordering.

Product code: 312846

Please compare the product code and specifications with the required application before ordering.
