Spin On Fuel Filter - B32013

The Spin On Fuel Filter - B32013 is a replacement filtration component for compatible marine applications.

Product information

• Racor - B32013 - Spin On Fuel Filter Element - With Clear Bowl - 10 Micron
• 10 Micron Aquabloc® Element and Bowl combination with 11/16"-16 Center Thread. Marine Gasoline FF/WS, 60 gph Flow Rate. Clear Bowl. Replaces Mercury, Mercruiser, Quicksilver, Yamaha, Suzuki, SMI, Volvo Penta, Sierra, AquaPower, Honda, Tohatsu etc.
• The filter body is protected with a durable electrostatically-applied powder coating for superior corrosion resistance. The spin-on filter design is simple to service and features a reusable clear engineering plastic or metal contaminant collection bowl with a self-venting drain for draining out collected contaminants and water.
• Aquabloc® elements repel water and remove solid contaminants from fuel at 98% efficiency of their micron rating. To meet the unique requirements of customers' engines, three different micron rating cartridges are available for purchase, including
• 30 micron - Ideally suited as a pre-filter to protect downstream filters from excessive contamination. Extends the life of on-engine filters.
• 10 micron - Captures more contaminants than 30 micron elements, and is more effective at stopping water. Extends the life of the entire fuel system.
• 2 micron - Provides maximum water removal and filtration and is capable of protecting all modern injection systems, while greatly extending the life of difficult-to-service on-engine filters.
• Technical Specifications
• Series: B32013 OEM Spin-On
• Micron Rating: 98% @ 10 Micron
• Outside Diameter: 3.8 in / 97 mm
• Height: 7.1 in / 180 mm
• Filter Element Type: 10 Micron Aquabloc® Spin-on with clear bowl
• Connection Type: 11/16"-16, 3.125" Female Bottom Threads
• Related Parts: S3213 Replacement Element
• Bowl: RK30475 / 18-7922

Before ordering

Please compare the listed specifications and part number with your existing component. If you need help confirming compatibility, contact Jet Ski Parts Warehouse with your make, model, year and engine details.
