Fuel Filter Water Separator - 230R2

The Fuel Filter Water Separator - 230R2 is a replacement filtration component for compatible marine applications.

Product information

• Racor - 230R2 200 Series Fuel Water Separator - 2 Micron Filter
• Racor's 220R2 Fuel Water Separators come complete with an integral primping pump and a see thru bowl.
• 114L/ Hour flow rate
• 1/4" NPT Ports
• R20 Series filter replacement
• Filters can be mounted on-engine or remotely, and come with hand-operated fuel priming pumps, which allow for easy filter replacement and air purge. When it's time for service, only the filter element is replaced—the bowl and drain plug are reused. Water-in-fuel (WIF) sensor upgrades are available for diesel applications to alert operators to drain accumulated water from the bowl.
• All Marine Spin-on Series Fuel Filter Water Separators utilize Racor's high-efficiency Aquabloc® engineered media, which repels water and removes solid contaminants from fuel at 98% efficiency of their micron rating. Depending on the product selected, three different micron ratings are available for purchase, including
• 30 micron – Ideally suited as a pre-filter to protect downstream filters from excessive contamination. Extends the life of on-engine filters.
• 10 micron - Captures more contaminants than 30 micron elements, and is more effective at stopping water. Extends the life of the entire fuel system.
• 2 micron – Provides maximum water removal and filtration and is capable of protecting all modern injection systems, while greatly extending the life of difficult-to-service on-engine filters.

Before ordering

Please compare the listed specifications and part number with your existing component. If you need help confirming compatibility, contact Jet Ski Parts Warehouse with your make, model, year and engine details.
